Size/Weight
| Dimensions | Width | 940 mm (37”) |
|---|---|---|
| Height | 109 mm (4-5/16”) | |
| Depth | 306 mm (12-1/16”) | |
| Weight | Weight | 3.4 kg (7 lbs 8 oz) (not including batteries) |
Control Interface
| Keyboard | Number of Keys | 61 |
|---|---|---|
| Touch Response | No | |
| Display | Type | LED display |
| Language | English | |
| Panel | Language | English |
Voices
| Tone Generation | Tone Generating Technology | AWM Stereo Sampling |
|---|---|---|
| Polyphony | Number of Polyphony (Max.) | 32 |
| Preset | Number of Voices | 120 |
Effects
| Types | Reverb | Yes (Fixed in Voice/Non controllable) |
|---|---|---|
| Chorus | Yes (Fixed in Voice/Non controllable) | |
| Functions | Panel Sustain | Yes |
Accompaniment Styles
| Preset | Number of Preset Styles | 114 |
|---|---|---|
| Fingering | Multi | |
| Style Control | Main, Fill-in |
Songs
| Preset | Number of Preset Songs | 30 |
|---|
Functions
| Lesson/Guide | Part Mute | |
|---|---|---|
| Overall Controls | Metronome | Yes |
| Tempo Range | 11 - 280 | |
| Transpose | -12 to 0, 0 to +12 | |
| Tuning | Yes | |
Storage and Connectivity
| Connectivity | DC IN | DC IN 12V |
|---|---|---|
| Headphones | Stereo MINI-Jack x 1 |
Amplifiers and Speakers
| Amplifiers | 2.5 W + 2.5 W | |
|---|---|---|
| Speakers | 8 cm x 2 | |
Power Supply
| Power Supply | AC Adaptor PA-130 or an equivalent recommended by Yamaha, or six "AA" size alkaline (LR6), manganese (R6) or Ni-MH rechargeable batteries | |
|---|---|---|
| Power Consumption | 6 W (with PA-130) | |
